1/2" AUTOMATIC DRAIN D704A
THB-F.R.L. Air Control Unit - AUTOMATIC DRAIN
管路末端全自動排水器
Air Filter/Regulator/Lubricator Modular (F.R.L. air control unit) / Air Combination / Air Source Treatment / Modular FRL Units / Air Preparation / Air Preparation Unit / Filter Regulator Lubricator Combinations / FRL Combination Units / Filter, Regulator, Lubricator Combinations / FRL Filtro regulador lubricador / Filtro FRL regulador lubrificador / Druckluft Aufbereitung / Filtro regolatore lubrificatore / Фильтр-влагоотделитель / Регулятор давления / Лубрикатор / Filtre régulateur lubrificateur / filtre, regulatorer, smøreapparater / Filter, regulatorer, smörjare / フィルタレギュレータ+ルブリケータ / FRLユニット / モジュラタイプF.R.L.コンビネーション / SARTLANDIRICI / ثلاث نقاط الجمع / 空氣調理組 / 三點過濾器
SPECIFICATION :
| Part No. | D704A | |
| Description | ||
| Medium | Air | |
| Port Gauge (PT,NPT) | 1/2” | |
| Proof Input Pressure | Psi | 175 |
| Mpa | 1.2 | |
| Drain Capacity | 27 ml | |
＊ Meet The International Norms : JIS B 8371
FEATURES :
1. High inlet pressure support
2. Longer life time
3. Auto drain design
4. Application for any end of pipe system
