TRUFLATE TYPE (AUTOMOTIVE) 1/4” BODY Plug - Hose Barb end
AIR QUICK COUPLING
TRUFLATE TYPE (AUTOMOTIVE) 1/4” BODY Plug - Hose Barb end
美式快速接頭(公) – 插心
Air Quick Coupler / Quick Disconnect Coupling / Quick Disconnector / Quick Connect / Quick Release Coupler (QRC) / Air Quick Coupling / Air Connectors & fitting / Quick coupling / Pneumatic couplings / Cople Rapido / Acople Rapido / Cngate rápido / Engate rápido para ar comprimido / Druckluftkupplungen / Schnellkupplungen / Stecknippel / Stecktüllen / Schnellverschluss-Kupplungen / Фитинг Муфта / Фитинг Штуцер / Connettore aria ad attacco rapido / Raccordi per aria compressa / Raccords rapides / Raccords et embouts / Trykluft koblinger og nipler / Snabbkopplingar och nipple / أداة تقرن / مقرنة /カプラー / カプラ / ハイカプラ / 空气用快速接头/相容接頭
| Part No. | Size |
| S21-20PHA | 1/4" HOSE |
| S21-30PHA | 3/8" HOSE |
FEATURES:
1. Compatible with other manufacturer’s Automotive / Tru-Flate Interchange.
2. Four & Six stainless steel locking balls design as option.
3. Yellow zinc dichromate-plated steel.
4. Certificate of RoHS compliance.
APPLICATION:
1. Pneumatic tools
2. Air piping
3. Air pressure equipment
SPECIFICATION:
| Material | Steel | Brass |
| Thread | NPT | |
| Working Pressure | 218PSI (15Bar/1.5MPa) | 145PSI (10Bar/1MPa) |
| Maximum Pressure | 290PSI (20Bar/2MPa) | 218PSI (15Bar/1.5MPa) |
| Temperature Range | -20℃ ~ +80℃ | |
| Size | 1/4" (20 Type) | |
| 3/8" (30 Type) | ||
