• SWIVEL MANIFOLD (SRT-S10)

SWIVEL MANIFOLD (SRT-S10)

Model : SRT-S10

AIR QUICK COUPLER

SWIVEL MANIFOLD with Three Nitto type couplers

鐵日式快速接頭旋轉三通

Air Quick Coupler / Quick Disconnect Coupling / Quick Disconnector / Quick Connect / Quick Release Coupler (QRC) / Air Quick Coupling / Air Connectors & fitting / Quick coupling / Pneumatic couplings / Cople Rapido / Acople Rapido / Cngate rápido / Engate rápido para ar comprimido / Druckluftkupplungen / Schnellkupplungen / Stecknippel / Stecktüllen / Schnellverschluss-Kupplungen / Фитинг Муфта / Фитинг Штуцер / Connettore aria ad attacco rapido / Raccordi per aria compressa / Raccords rapides / Raccords et embouts / Trykluft koblinger og nipler / Snabbkopplingar och nipple / أداة تقرن / مقرنة /カプラー / カプラ / ハイカプラ / 空气用快速接头/相容接頭

SPECIFICATION:

                     Part No.   SRT-S10SRL-S10 SRLL-S10 SRT-S13 SRLS13 SRLL-S13 SRT-S27 SRL-S27 SRLL-S27 SRT-S31 SRL-S31 SRLL-S31
  Description
  Coupler Nitto Standard

Nitto         One-Touch

Universal Type Rectus Type
  Thread PT NPT G
  Working Pressure 218PSI (15Bar/1.5Mpa)
  Maximum Pressure 290PSI (20Bar/2Mpa)
  Temperature Range -20℃ ~ +80℃
  Port Size 1/4"

FEATURES:

1. Three or two couplers can apply for three or two working stations.

2. The manifold can be 360 rotated which would be more convenience for users.

3. The couplers can be replaced in Nitto type, American type or European type for various market demands.

APPLICATION:

1. Pneumatic tools

2. Air piping

3. Air pressure equipment
