3/8"BODY COUPLER SMA(S24)
AIR QUICK COUPLER
INDUSTRIAL TYPE 3/8” BODY - Male thread
美式快速接頭(母) – 外牙
Air Quick Coupler / Quick Disconnect Coupling / Quick Disconnector / Quick Connect / Quick Release Coupler (QRC) / Air Quick Coupling / Air Connectors & fitting / Quick coupling / Pneumatic couplings / Cople Rapido / Acople Rapido / Cngate rápido / Engate rápido para ar comprimido / Druckluftkupplungen / Schnellkupplungen / Stecknippel / Stecktüllen / Schnellverschluss-Kupplungen / Фитинг Муфта / Фитинг Штуцер / Connettore aria ad attacco rapido / Raccordi per aria compressa / Raccords rapides / Raccords et embouts / Trykluft koblinger og nipler / Snabbkopplingar och nipple / أداة تقرن / مقرنة /カプラー / カプラ / ハイカプラ / 空气用快速接头/相容接頭
| Part No. | Size |
| S24-20SMA | 1/4" NPT |
| S24-30SMA | 3/8" NPT |
| S24-40SMA | 1/2" NPT |
FEATURES:
1. 3/8” body design for Industrial Interchange
2. Compatible with other manufacturer’s Industrial / Automotive / Tru-Flate interchange.
3. Six & Eight stainless steel locking balls design as option.
4. Certificate of RoHS compliance.
APPLICATION:
1. Pneumatic tools
2. Air piping
3. Air pressure equipment
SPECIFICATION:
| Material | Steel |
| Thread | NPT |
| Working Pressure | 218PSI (15Bar/1.5MPa) |
| Maximum Pressure | 290PSI (20Bar/2MPa) |
| Temperature Range | -20℃ ~ +80℃ |
| Size | 1/4"(20 TYPE) |
| 3/8"(30 TYPE) | |
| 1/2"(40 TYPE) |
