• PARTICULATE FILTER - 89 SERIES (STANDARD)

PARTICULATE FILTER - 89 SERIES (STANDARD)

Model : F89

F.R.L. AIR CONTROL UNIT

Air Filter (Regular type

濾水器

Air Filter/Regulator/Lubricator Modular (F.R.L. air control unit) / Air C ombination / Air Source Treatment / Modular FRL Units / Air Preparation / Air Preparation Unit / Filter Regulator Lubricator Combinations / FRL Combination Units / Filter, Regulator, Lubricator Combinations / FRL Filtro regulador lubricador / Filtro FRL regulador lubrificador / Druckluft Aufbereitung / Filtro regolatore lubrificatore / Фильтр-влагоотделитель / Регулятор давления / Лубрикатор / Filtre régulateur lubrificateur / filtre, regulatorer, smøreapparater / Filter, regulatorer, smörjare / フィルタレギュレータ+ルブリケータ / FRLユニット / モジュラタイプF.R.L.コンビネーション / SARTLANDIRICI / ثلاث نقاط الجمع / 空氣調理組 / 三點過濾器

SPECIFICATION:

                Part No.                 Description F892 F893 F894 F832 F833 F834
  Medium Air
  Port Size (PT, NPT) 1/4” 3/8” 1/2” 1/4” 3/8” 1/2”
  Filter Element
Proof Input Pressure  Psi 215 250
Mpa 1.5 1.7

   Proof Output

   Pressure

Psi 145 215
Mpa 0.99 1.5
  Max Flow (L/min) 1750 2500 3000 1750 2500 3000
  Operation Temperature Range 5℃ ~  60℃
  Drain Capacity 80 ml

FEATURES:

1. Steel guards offer better protection.

2. Easy installation and disassembly.



ORDER INFORMATION:
