RECOIL PU TWIN HOSE
Model :
HUMR
THB-AIR HOSE - TWIN HOSE
RECOIL PU/PU BRAID TWIN HOSE
| Part No. | I.D(mm) | O.D(mm) | Length (M) | Temperature | Working Pressure |
| HBMR2504 | 2.5 | 4 |
5 10 15 |
-20°C~60°C (-5°F~140°F) | 150PSI (10Bar/1MPa) |
| HBMR0406 | 4 | 6 | |||
| HBMR0508 | 5 | 8 | |||
| HBMR6510 | 6.5 | 10 | |||
| HBMR0812 | 8 | 12 | 135PSI (9Bar/0.9MPa) |
RECOIL PU/PU TWIN HOSE
| Part No. | I.D(mm) | O.D(mm) | Length (M) | Temperature | Working Pressure |
| HUMR0508 | 5 | 8 | 5 | -20°C~60°C (-5°F~ 140°F) | 150PSI (10Bar/1MPa) |
| HUMR6510 | 6.5 | 10 | 10 | ||
| HUMR0812 | 8 | 12 | 15 | 135PSI (9Bar/0.9MPa) |
RECOIL PU BRAID/PU BRAID TWIN HOSE
| Part No. | I.D(mm) | O.D(mm) | Length (M) | Temperature | Working Pressure |
| HBBMR0508 | 5 | 8 | 5 | -20°C~60°C (-5°F~ 40°F) | 200PSI (14Bar/1.4MPa) |
| HBBMR6510 | 6.5 | 10 | 10 | ||
| HBBMR0812 | 8 | 12 | 15 |
FEATURES：
1. Different size & colors are available.
2. PU braid hose for high pressure air, PU air hose for water based paint
3. Uniweld hose can save space and prevent knot issue.
4. Twin hose can be identified and managed easily
