• STANDARD QUICK COUPLER SPA

STANDARD QUICK COUPLER SPA

Model : SPA

AIR QUICK COUPLING

JAPANESE  STYLE - REGULAR TYPE (for Hose usage)

日式快速接頭 – 搭配PU

Air Quick Coupler / Quick Disconnect Coupling / Quick Disconnector / Quick Connect / Quick Release Coupler (QRC) / Air Quick Coupling / Air Connectors & fitting / Quick coupling / Pneumatic couplings / Cople Rapido / Acople Rapido / Cngate rápido / Engate rápido para ar comprimido / Druckluftkupplungen / Schnellkupplungen / Stecknippel / Stecktüllen / Schnellverschluss-Kupplungen / Фитинг Муфта / Фитинг Штуцер / Connettore aria ad attacco rapido / Raccordi per aria compressa / Raccords rapides / Raccords et embouts / Trykluft koblinger og nipler / Snabbkopplingar och nipple / أداة تقرن / مقرنة /カプラー / カプラ / ハイカプラ / 空气用快速接头/相容接頭


Part No. Size
20SPA 5x8mm hose
30SPA 6.5x10mm hose
40SPA 8x12mm hose
45SPA 10x14mm hose
50SPA 11x16mm hose


FEATURES:

1. One-way automatic shut-off valve in the socket.

2. Wide variety provides best choice accordingly to application.

3. Hardened important parts are extremely wear resistant and durable.

4. Tested 100,000 times, coupler connection is accurate and reliable.

APPLICATION:

1. Pneumatic tools

2. Air piping

3. Air pressure equipment

SPECIFICATION:

  Material Stainless Steel
  Thread PT
  Working Pressure 218PSI (15Bar/1.5MPa)
  Maximum Pressure 290PSI(20Bar/2MPa)
 Temperature Range -20℃ ~ +80℃
  Size 1/4" (20Type)
3/8" (30Type)
1/2" (40Type)

*Meet The International Norms : JIS B 0203
