• 1/4”BODY COUPLER(S29)

1/4”BODY COUPLER(S29)

Model : SHA (S29)

AIR QUICK COUPLER

INDUSTRIAL TYPE 1/4” BODY - Hose Barb end

美式快速接頭() - 插心

Air Quick Coupler / Quick Disconnect Coupling / Quick Disconnector / Quick Connect / Quick Release Coupler (QRC) / Air Quick Coupling / Air Connectors & fitting / Quick coupling / Pneumatic couplings / Cople Rapido / Acople Rapido / Cngate rápido / Engate rápido para ar comprimido / Druckluftkupplungen / Schnellkupplungen / Stecknippel / Stecktüllen / Schnellverschluss-Kupplungen / Фитинг Муфта / Фитинг Штуцер / Connettore aria ad attacco rapido / Raccordi per aria compressa / Raccords rapides / Raccords et embouts / Trykluft koblinger og nipler / Snabbkopplingar och nipple / أداة تقرن / مقرنة /カプラー / カプラ / ハイカプラ / 空气用快速接头/相容接頭


Part No. Size
S29-20SHA  1/4" HOSE
S29-30SHA  3/8" HOSE


FEATURES:

1. Compact design

2. Compatible with other manufacturer’s Industrial Interchange.

3. Six stainless steel locking balls design.

4. Certificate of RoHS compliance.

APPLICATION:

1. Pneumatic tools

2. Air piping

3. Air pressure equipment

SPECIFICATION:

 Material Steel
 Thread NPT
 Working Pressure 218PSI (15Bar/1.5MPa)
 Maximum Pressure 290PSI (20Bar/2MPa)
 Temperature Range -20℃ ~ +80℃
 Size 1/4"(20 TYPE)
3/8"(30 TYPE)

 * Meet The International Norms : ANSI / ASME B1.20.1 / DIN 2999
